We have invested in the best equipment, environment and staff training. We have a production capability for standard and HDI, Rigid, RF and high frequency PCBs, together with through hole and min 0201 chips, 0.2mm pitch BGA balls SMD soldering, in small batch, mid volume and high volume quantities.
Professional PCB electronics manufacture services, every PCB enquiry or order is handled in the strictest of confidence. We can fabricate Laser holes, Impedance Control PCB, Buried & Blind Holes PCB, Countersunk hole, and other special material or special process PCBs.
TOP PCB High frequency - Microwave Circuits Roger 4000+ FR4 Mixed Pressure
| Items | Capacity |
|---|---|
| Base Material | Roger 4000+ FR4 Mixed pressure |
| Layer / pcb thickness | 6 Layer / 1.6mm |
| Copper thickness | 1oz copper |
| Solder mask / silkscreen | green solder mask/ white silkscreen |
| Surface finished | immersion gold |
| Min width/space | 4.5 / 3.5 mil |
| Min holes | 0.2mm |
| Technics Characteristic | trace width ± 10 % |
| Standard Produce time | 9-12 days |
| Fast produce time | 24h ~ 90h |
We have established a quality system with ISO9001 and strictly implement the IPC class III standard to inspect the quality. 100% inspection includes electric test and AOI inspection. It can carry out high voltage test, impedance test, microsection, weldability test and other professional tests.
We have been manufacturing printed circuit boards for more than 20 years, established in 1990. As a high-quality PCB manufacturer, we handle small to medium volume production quantities. Whether it is a prototype printed circuit board assembly or large volume PCB production, we have the capacity and the knowledge to satisfy all of your production requirements.
We have over 15 professional engineers, and all products are tested before shipping. We maintain large stocks of products to serve your needs quickly.
We pay attention to offering a complete and safe package.
PCB: Sealed bag, Anti-static bags, Suitable carton.
PCBA: Antistatic foam bags, Anti-static bags, Suitable carton.
